| Level |
Standard |
| Resolution |
8 dots/mm (203DPI) |
| Printing Method |
Direct Thermal |
| Max. Print Speed |
203mm (8”)/second |
| Max. Print Width |
104mm (4.09”) |
| Max. Print Length |
2,794mm (110”) |
| CPU |
400 MHz, 32 bits, ARM9 |
| Memory RAM |
64 MB SDRAM |
| Memory ROM |
32 MB Flash |
| Interface |
- USB 2.0 High Speed 480Mbps
- USB Host 2.0, for scanner or PC keyboard
- Ethernet 10/100Mbps
- RS-232
- Internal Bluetooth 4.2 frequency (factory option)
- Internal Wi-Fi (factory option)
|
| Buzzer |
Optional |
| Sensors |
Head open sensor, Black mark reflective sensor (moveable), Gap transmissive sensor (moveable) |
| Power |
External universal switching power supply Input: AC 100-240V, 2.5A, 50-60Hz. Output: DC 24V, 2.5A, 60W |
| User Interface |
- 1 power switch
- 2 buttons (Feed & Pause)
- 2 LEDs (Online, Error)
|
| Internal Fonts |
- 8 alpha-numeric bitmap fonts
- True type font engine (need download scalable font file)
|
| 1D Barcode |
Code 11, Code 39, Code 93, Code 128 (subsets A, B, C), UPC-A, UPC-E, UCC-128, Codabar, EAN/JAN-8, EAN/JAN-13, Interleaved 2 of 5, ITF14, MSI Plessey, Postcode, Telepen |
| 2D Barcode |
QR Code, Micro QR Code, PDF417, Micro PDF417, Grid Matrix, MaxiCode, Aztec Code, Data Matrix |
| Rotation |
Font and barcode support 0, 90, 180, 270 degree |
| Printer Language |
Compatible to TSPL, EPL, EPL 2, ZPL, ZPL II, DPL |
| Media Type |
Continuous, die-cut, black mark, fan-fold, notched (outside wound) |
| Media Width |
25.4~118mm (0.9"~4.6") |
| Label Roll Capacity |
127 mm (5”) OD |
| Physical Dimension |
180mm(W) x 174.7mm(H) x 238mm(L) |
| Net Weight |
1.85kg |
| Enclosure |
ABS plastic |
| Environment Condition |
Operation: 5~40°C, 25~85% non-condensing Storage: -40~60°C, 10~90% non-condensing |
| Environment Concern |
Comply with RoHS, REACH, WEEE |
